2011 Arctic Cat ARCTIC CAT SNO PRO 600 — KIT PARTS LIST (MODIFIED RACE SLED: RACE GAS)
2011 ARCTIC CAT SNO PRO 600
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 2900-055 | KIT,MOD-RACE GAS | 1 | $3,664.95 | |
| 2 | 2900-057 | DOME,BILLIT-16:1 | 1 | $163.95 | |
| 3 | 2900-058 | FLANGE,EXHAUST | 1 | $91.95 | |
| 4 | 2900-059 | CHAMBER,EXPANSION-MAG | 1 | $770.95 | |
| 5 | 2900-060 | CHAMBER,EXPANSION-PTO | 1 | $899.95 | |
| 6 | 2612-142 | SPRING,PIPE-LONG-SPEEDWERX | 1 | $21.95 | |
| 7 | 2612-143 | SPRING,PIPE-SHORT-SPEEDWERX | 1 | $20.95 | |
| 9 | 2900-061 | SILENCER | 1 | $594.95 | |
| 10 | 6506-417 | JET NEEDLE-J8-9DGH18-53 | 1 | $32.95 | |
| 11 | 6505-262 | JET PILOT 50 | 1 | $4.95 | |
| 12 | 6505-127 | JET MAIN 460 | 1 | $6.75 | |
| 13 | 0746-823 | CAM,ARM-P7-N-W/BEARING | 1 | $89.95 | |
| 14 | 0646-160 | BEARING,CAM ARM | 1 | $15.11 | |
| 15 | 0646-410 | SPRING,CLUTCH-BLUE SPEEDWERX | 1 | $97.95 | |
| 16 | 0648-789 | CAM ASSY-TEAM L/W-68-48-36/64-48-41 | 1 | $270.95 | |
| 17 | 2900-062 | SPRING,DRIVEN-180/300 | 1 | $87.95 | |
| 18 | 0612-111 | BUMPER,MOLDED-RUBBER | 1 | $16.49 |
