WATER PUMP ASSEMBLY
2012 TZ1
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3007-178 | PUMP ASSY,WATER | 1 | $517.95 | |
| 2 | 3007-179 | IMPELLER/SHAFT | 1 | $93.95 | |
| 3 | 3007-180 | SEAL,MECHANICAL | 1 | $52.95 | |
| 4 | 3003-615 | BEARING,OIL PUMP DRIVESHAFT,M10X26X8 | 1 | $34.95 | |
| 5 | 3402-465 | OIL SEAL (M10X21X5) | 1 | $16.49 | |
| 6 | 3007-181 | O RING | 1 | $13.73 | |
| 7 | 3423-404 | O RING | 1 | $22.01 | |
| 8 | 3007-511 | SCREW | 1 | $2.47 | |
| 9 | 3007-512 | E RING | 1 | $3.71 | |
| 10 | 3007-503 | BOLT,MAGNETO COVER | 1 | $3.16 |
