A-ARM ASSEMBLY
2013 M 800 SNO PRO 153
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 2703-966 | ARM,UPPER-RH 38"-PTD WHT | 1 | $163.95 | |
| 1 | 2703-967 | ARM,UPPER-LH 38"-PTD WHT | 1 | $163.95 | |
| 2 | 8408-845 | SCREW,CAP-HFH M8X1.25X45 CL8.8 Z&Y | 1 | $1.09 | |
| 3 | 2603-841 | AXLE,A-ARM-UPPER-PM | 1 | $2.06 | |
| 4 | 8427-802 | NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z&Y | 1 | $0.54 | |
| 5 | 8427-202 | NUT,HEX FLG-NYL LOCK M12X1.25 CL8 Z&Y | 1 | $1.23 | |
| 6 | 2703-970 | A-ARM,LOWER-RH 38" WHT-FABR | 1 | $232.95 | |
| 6 | 2703-971 | A-ARM,LOWER-LH 38" WHT-FABR | 1 | $232.95 | |
| 7 | 1603-895 | BEARING, 10DU10-FRONT SUSPENSION | 1 | $5.37 | |
| 8 | 2603-911 | BEARING,SPLIT-18 X 20 X 15 | 1 | $4.13 | |
| 9 | 1623-965 | NUT,HEX-THK NYL M12X1.25 CL8 Z&Y(DIN) | 1 | $1.50 | |
| 10 | 2603-909 | BRACE,LOWER A-ARM | 1 | $9.59 | |
| 11 | 2603-916 | AXLE,A-ARM-LWR FRT | 1 | $13.73 | |
| 12 | 1623-953 | SCREW,CAP-HFH M12X1.25X76 CL 10.9 MZ | 1 | $3.44 | |
| 13 | 8409-075 | SCREW,CAP-HFH M10X1.25X75 CL10.9 Z&Y | 1 | $1.92 | |
| 14 | 2603-543 | AXLE, A-ARM-LWR-REAR | 1 | $3.99 | |
| 15 | 8427-002 | NUT,HEX FLG-NYL LOCK M10X1.25 CL8 Z&Y | 1 | $0.95 |
