BATTERY AND TRAY ASSEMBLY
2014 XF 9000 HIGH COUNTRY
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0745-406 | BATTERY,SEALED-YTX20-ASSY | 1 | $154.95 | |
| 2 | 0645-430 | LABEL,POISON/DANGER-HORIZ FORMAT | 1 | $1.64 | |
| 3 | 0445-082 | HARDWARE,BATTERY-PACK (010 ATV) | 1 | $10.97 | |
| 4 | 0645-647 | BRKT, HOLDDOWN-BATTERY | 1 | $27.95 | |
| 5 | 8468-625 | SCREW,MACH-TSPNH M6X1.0X25 CL8.8 BLK | 1 | $0.68 | |
| 6 | 8427-602 | NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z&Y | 1 | $0.12 | |
| 7 | 0445-092 | SOLENOID,STARTER RELAY | 1 | $49.95 | |
| 8 | 0645-649 | CABLE,BATTERY-SOLENOID | 1 | $19.25 | |
| 9 | 0645-662 | BOOT,BATTERY CABLE | 1 | $8.95 | |
| 10 | 0645-697 | BOOT,BATTERY CABLE | 1 | $19.25 | |
| 11 | 0623-038 | NUT,HEX M6 Z&Y-SEMS (W/WASHER) | 1 | $0.26 | |
| 12 | 0645-671 | CABLE,SOLENOID TO STARTER-TURBO | 1 | $46.95 | |
| 13 | 0645-019 | BOOT,TERMINAL-BATTERY | 1 | $4.40 | |
| 14 | 1623-451 | BOLT, STARTER MOTOR-HH SEMS M5X0.8X8 Z&Y | 1 | $3.44 | |
| 15 | 0645-670 | CABLE,BATTERY-GROUND-TURBO | 1 | $38.95 | |
| 16 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 |
