2015 Arctic Cat XF 7000 HIGH COUNTRY 141 SNO PRO — SEAT ASSEMBLY
2015 XF 7000 HIGH COUNTRY 141 SNO PRO
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 5706-848 | SEAT,ASSY-XF/M 7000 | 1 | $713.95 | |
| 2 | 5706-847 | COVER,SEAT-M/XF 7000 | 1 | $382.95 | |
| 3 | 0717-216 | FOAM,SEAT-MTN 7000 | 1 | $132.95 | |
| 4 | 0624-528 | STAPLE,5/16L X 1/2W-20GA SS/5000 PAK-SEA | 1 | $161.95 | |
| 5 | 5706-770 | BASE,SEAT-ASSY | 1 | $54.95 | |
| 6 | 6606-833 | HOOK,SEAT LATCH | 1 | $17.87 | |
| 7 | 8061-708 | RIVET, BLIND-LF SS66 BLACK | 1 | $0.95 |
