2017 Arctic Cat LYNX 2000 — REED VALVE ASSEMBLY
2017 LYNX 2000
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3006-012 | VALVE ASSY,REED | 1 | $283.95 | |
| 2 | 3006-013 | STOPPER,REED VALVE | 1 | $20.95 | |
| 3 | 3006-014 | VALVE,REED | 1 | $24.77 | |
| 4 | 3006-083 | SCREW,REED VALVE '02 570 F/C | 1 | $3.44 | |
| 5 | 3006-084 | PLATE,REED VALVE '02 570 F/C | 1 | $4.40 | |
| 6 | 3006-529 | BOLT,6 X 20 | 1 | $3.44 |
