2017 Arctic Cat M 8000 LTD 153 — REAR SUSPENSION FRONT ARM SHOCK ABSORBER
2017 M 8000 LTD 153
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 2603-511 | VALVE,AIR-LOW TEMP (FOX) | 1 | $32.95 | |
| 2 | 2603-965 | SEAL,CAP-EVOL AIR VALVE-.296"ODX.125"ID | 1 | $1.64 | |
| 3 | 3603-367 | CAP,VALVE-EVOL-BLACK | 1 | $3.99 | |
| 5 | 3603-365 | DECAL,BAND-PERFORMANCE SERIES | 1 | $17.87 | |
| 6 | 3603-373 | DECAL,FLOAT X EVOL | 1 | $20.63 | |
| 8 | 4639-012 | FLOAT FLUID,FOX RACING SHOX-8 OZ | 1 | $18.95 | |
| 9 | 5639-530 | SEMI-SYN SHOCK OIL-1 QUART | 1 | $26.95 |
