BELT GUARD ASSEMBLY
2017 PANTERA 7000 XT LTD
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 2 | 1623-637 | CLIP,U-NUT (M5) | 1 | $2.47 | |
| 3 | 8450-079 | WASHER, FLAT-M5-5.78X20X2.30-Z&Y | 1 | $3.57 | |
| 4 | 8476-520 | SCREW,MACH-TSTRH M5X0.8X20 Z&Y | 1 | $1.64 | |
| 5 | 1611-565 | DECAL,WARNING-GUARD | 1 | $1.92 | |
| 7 | 1623-052 | NUT,U | 1 | $0.95 | |
| 8 | 8060-686 | RIVET,BLIND-DH SS64 ZINC | 1 | $0.40 | |
| 9 | 0623-797 | SCREW,SELF TAP-TSTH 10-12X1/2 WO/GP | 1 | $0.45 |
