REAR BUMPER, STORAGE, AND TAILLIGHT ASSEMBLY
2017 XF 7000 CROSSTOUR
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 6606-697 | LID,STORAGE BOX | 1 | $157.95 | |
| 2 | 4606-926 | STRAP,HOLDDOWN-STORAGE BOX LID | 1 | $4.68 | |
| 4 | 6606-684 | FACIA,RACK-FRONT-RH-MOLD BLK | 1 | $133.95 | |
| 4 | 6606-685 | FACIA,RACK-FRONT-LH-MOLD BLK | 1 | $133.95 | |
| 6 | 1623-129 | R/B 2623-166 | 1 | $0.35 | |
| 10 | 0609-898 | TAILLIGHT,RED | 1 | $66.95 | |
| 11 | 8476-512 | SCREW,MACH-TSTRH M5X0.8X12 Z&Y | 1 | $1.23 | |
| 12 | 2623-017 | SCREW,SELF-TAP-TSTRH-M6X12-BOSCRW | 1 | $1.37 | |
| 13 | 0641-897 | OUTLET, ACCESSORY - 12V DC | 1 | $23.39 | |
| 14 | 4718-346 | PANEL,REAR BUMPER-RH W/REFLECTORS | 1 | $62.95 | |
| 14 | 4718-347 | PANEL,REAR BUMPER-LH W/REFLECTORS | 1 | $62.95 | |
| 15 | 5611-852 | DECAL,WARNING-TOWING/TRACK-FRENCH | 1 | $2.47 | |
| 16 | 5611-853 | DECAL,WARNING-TOWING/TRACK-ENGLISH | 1 | $2.47 | |
| 17 | 1621-394 | DECAL,REFLECTOR-RED-RH | 1 | $24.77 | |
| 17 | 1621-395 | DECAL,REFLECTOR-RED-LH | 1 | $24.77 | |
| 18 | 0617-742 | SEAL,FOAM-.187X.375X20.5 | 1 | $5.37 | |
| 19 | 1623-661 | SCREW,PT THD-TSTRH K60-2.69X16MM RIE BLK | 1 | $2.33 | |
| 20 | 1707-628 | BUMPER,REAR-TOUR-PTD BLK | 1 | $227.95 | |
| 21 | 8060-706 | RIVET,BLIND-DH SS64 BLK | 1 | $0.40 | |
| 22 | 0423-577 | CLIP,U-NUT M6 | 1 | $0.40 | |
| 23 | 8477-620 | SCREW,MACH-TSTRH M6X1.0X20 Z&BLK | 1 | $0.54 | |
| 24 | 2621-316 | DECAL,CAPACITY-STORAGE BOX | 1 | $12.35 |
