SKID PLATE AND SIDE PANEL ASSEMBLY
2018 M 8000 SNO PRO ES 153 (2.6)
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 5718-702 | PANEL,SIDE-RH BLK-W/DECAL | 1 | $243.95 | |
| 1 | 5718-600 | PANEL,SIDE-RH BLK-W/WARNING DECAL | 1 | $212.95 | |
| 2 | 4621-813 | DECAL,WARNING-FRENCH | 1 | $9.59 | |
| 3 | 1623-939 | NUT,SPEED-#10 B "U" TYPE | 1 | $1.23 | |
| 6 | 0617-790 | FOAM,SIDE PANEL-LWR REAR RH (M) | 1 | $24.77 | |
| 7 | 7606-644 | FOIL,SIDE PANEL-LOWER RH (M) | 1 | $6.06 | |
| 8 | 7606-646 | FOIL,SIDE PANEL-UPPER RH (M) | 1 | $10.97 | |
| 9 | 7606-650 | FOIL,SIDE PANEL-MID RH (M) | 1 | $6.06 | |
| 10 | 0617-792 | FOAM,SIDE PANEL-MID RH (M) | 1 | $15.11 | |
| 11 | 0617-788 | FOAM,SIDE PANEL-LWR FRT RH (M) | 1 | $15.11 | |
| 12 | 5718-703 | PANEL,SIDE-LH BLK-W/DECAL | 1 | $243.95 | |
| 12 | 5718-601 | PANEL,SIDE-LH BLK-W/WARNING DECAL | 1 | $212.95 | |
| 13 | 4621-812 | DECAL,WARNING-ENGLISH | 1 | $9.59 | |
| 14 | 0617-791 | FOAM,SIDE PANEL-LWR REAR LH (M) | 1 | $24.77 | |
| 15 | 0617-789 | FOAM,SIDE PANEL-LWR FRT LH (M) | 1 | $15.11 | |
| 16 | 0617-793 | FOAM,SIDE PANEL-MID LH (M) | 1 | $15.11 | |
| 17 | 7606-640 | VENT,UPPER SIDE PANEL-RH (MTN) | 1 | $9.59 | |
| 17 | 7606-641 | VENT,UPPER SIDE PANEL-LH (MTN) | 1 | $9.59 | |
| 18 | 0123-987 | CLIP,U-TYPE | 1 | $0.68 | |
| 19 | 7606-682 | BRACE,SIDE PANEL-2-STRK-MTN | 1 | $13.73 | |
| 20 | 0617-797 | TAPE,VHB 5952 | 1 | $2.88 | |
| 21 | 5718-790 | PLATE,SKID-BLK RH-W/FOAM (MTN) | 1 | $121.95 | |
| 23 | 0617-794 | FOAM,SKID PLATE-MIDDLE RH (M) | 1 | $15.11 | |
| 24 | 3612-328 | FOIL,HEAT-SKID PLATE | 1 | $9.59 | |
| 25 | 0123-802 | WASHER,FLAT .194X.50X.048-Z&Y | 1 | $0.12 | |
| 26 | 3612-232 | PLATE,EXHAUST OUTLET | 1 | $13.73 | |
| 30 | 8061-712 | RIVET,BLIND-LF SS73 BLACK | 1 | $0.81 | |
| 31 | 5718-791 | PLATE,SKID-BLK LH-W/FOAM (MTN) | 1 | $121.95 | |
| 33 | 0617-795 | FOAM,SKID PLATE-MIDDLE LH (M) | 1 | $15.11 | |
| 36 | 2623-005 | CLIP,RECEPTACLE-1/4 TURN STUD | 1 | $2.61 | |
| 41 | 8061-708 | RIVET, BLIND-LF SS66 BLACK | 1 | $0.95 | |
| 42 | 2712-099 | SHIELD,HEAT BARRIER (M) | 1 | $78.95 | |
| 43 | 6606-940 | SHIELD,HEAT-ECU | 1 | $26.95 | |
| 44 | 8408-620 | SCREW,CAP-HFH M6X1.0X20 CL8.8 Z&Y | 1 | $1.37 | |
| 45 | 0730-297 | ECM,PROGRAMMED-8T/3.0P-8000 | 1 | $2,029.95 | |
| 46 | 0423-031 | NUT,SPEED M6 X 1.0 U-TYPE | 1 | $0.95 | |
| 47 | 7606-654 | BUMPER,PROTECTOR-RUBBER-8000 | 1 | $25.95 | |
| 48 | 7606-621 | BRACE,SKID PLATE-2-STRK-MTN | 1 | $10.97 | |
| 50 | 2712-103 | DEFLECTOR,EXHAUST OUTLET-OUTER-PTD BLK | 1 | $41.95 | |
| 51 | 8061-710 | RIVET,BLIND-LF SS68 BLACK | 1 | $1.09 |
