2018 Arctic Cat XF 9000 HIGH COUNTRY LTD 153 (1.75) — SKID PLATE AND SIDE PANEL ASSEMBLY
2018 XF 9000 HIGH COUNTRY LTD 153 (1.75)
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 5718-782 | PANEL,SIDE-RH BLK-W/DECAL | 1 | $367.95 | |
| 1 | 5718-030 | PANEL,SIDE-RH BLK-W/WARNING DECAL | 1 | $339.95 | |
| 3 | 1623-939 | NUT,SPEED-#10 B "U" TYPE | 1 | $1.23 | |
| 7 | 3612-322 | FOIL,HEAT-SIDE PANEL-UPR FWD-RH | 1 | $10.97 | |
| 8 | 3612-324 | FOIL,HEAT-SIDE PANEL-UPR RH | 1 | $10.97 | |
| 14 | 5718-783 | PANEL,SIDE-LH BLK-W/DECAL | 1 | $367.95 | |
| 14 | 5718-031 | PANEL,SIDE-LH BLK-W/WARNING DECAL | 1 | $149.95 | |
| 25 | 3612-326 | FOIL,HEAT-SKID PLATE | 1 | $19.25 | |
| 26 | 3612-330 | FOIL,HEAT-SKID PLATE | 1 | $2.88 | |
| 29 | 8061-708 | RIVET, BLIND-LF SS66 BLACK | 1 | $0.95 | |
| 35 | 2623-005 | CLIP,RECEPTACLE-1/4 TURN STUD | 1 | $2.61 | |
| 39 | 1623-933 | SCREW,PLASTITE-TXSPNH 10-14X3/4 Z&B | 1 | $0.26 | |
| 40 | 7606-620 | BRACE,SKID PLATE-4-STRK-MTN | 1 | $82.95 |
