SEAT ASSEMBLY
1993 TIGERSHARK DAYTONA
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 3 | 0773-005 | FOAM,SEAT | 1 | $105.95 | |
| 5 | 0624-263 | STAPLE,S.S. 3/8"PKG OF 1,250 ARROW | 1 | $133.95 | |
| 6 | 0673-051 | HOOK,SEAT BASE | 1 | $6.29 | |
| 8 | 0624-046 | SCREW,CAP-HH 6MM-1.0X16MM SS | 1 | $1.19 | |
| 9 | 0624-087 | SCREW,CAP HH 8MM1.25TX35MM (SS) | 1 | $4.19 | |
| 10 | 0624-061 | NUT,JAM 8MM 1.25T (SS) | 1 | $1.19 | |
| 11 | 0624-125 | WASHER FLAT,FENDER 8MM (SS) | 1 | $1.69 | |
| 12 | 0624-090 | NUT,LOCK-HH M8-1.25 (SS) | 1 | $1.89 | |
| 13 | 0624-022 | WASHER,FLAT-6MM SS | 1 | $0.22 | |
| 14 | 1611-687 | DECAL,CAUTION-TOWING | 1 | $6.95 | |
| 15 | 0624-128 | SCREW CAP HH-6MM 1.0TX10MM | 1 | $0.76 | |
| 17 | 0623-391 | WASHER,RUBBER 10MM ID | 1 | $5.79 | |
| 18 | 0673-083 | BUSHING,STEERING NOZZLE | 1 | $5.29 | |
| 19 | 0673-026 | LEVER,RELEASE-SEATLATCH | 1 | $8.59 | |
| 20 | 0773-941 | HOUSING,LATCH-UPPER/LOWER (1673-634/635) | 1 | $9.95 | |
| 21 | 0673-023 | CLIP,SPRING RETAINING-SS | 1 | $39.95 | |
| 23 | 0624-013 | WASHER,FLAT.42X.93X.075 SS | 1 | $1.79 | |
| 26 | 0624-047 | NUT,HEX JAM-10MM SS | 1 | $2.59 |
