1994 Arctic Cat MONTE CARLO — HANDLEBAR ASSEMBLY
1994 MONTE CARLO
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0405-039 | GRIP,HANDLE BAR | 1 | $20.63 | |
| 2 | 0773-018 | THROTTLE ASSY. (93) | 1 | $59.95 | |
| 4 | 0605-236 | PIN,THROTTLE LEVER PIVOT | 1 | $4.39 | |
| 5 | 0605-235 | HOUSING,THROTTLE | 1 | $37.95 | |
| 7 | 0624-113 | RING,RETAINING (SS) | 1 | $1.39 | |
| 8 | 0624-091 | SCREW,MACH PHPNH 6MM 1.0TX15MM (SS) | 1 | $2.19 | |
| 10 | 0673-282 | CAP,STEERING ADJUSTER | 1 | $20.63 | |
| 11 | 0673-992 | HANDLE BAR | 1 | $175.95 | |
| 12 | 0605-244 | PAD,HANDLEBAR-FRONT | 1 | $47.79 | |
| 13 | 0624-021 | NUT,LOCK-HEX6MM 1.0T SS | 1 | $0.78 | |
| 14 | 0123-788 | TIE,CABLE-8.5/7.5/7.4 | 1 | $0.12 | |
| 15 | 0609-202 | SWITCH,START/STOP/TETHER/BILGE | 1 | $432.95 | |
| 18 | 0605-419 | POST,STEERING-ASSY | 1 | $257.95 | |
| 19 | 0687-054 | CABLE,THROTTLE | 1 | $196.95 | |
| 21 | 0605-253 | PAD,HANDLEBAR-REAR | 1 | $37.95 | |
| 23 | 0686-246 | HARNESS,BILGE | 1 | $43.29 | |
| 25 | 0673-477 | CAP,END-GRIP | 1 | $1.09 | |
| 26 | 0637-077 | KIT,HANDLEBAR GRIP UPDATE | 1 | $11.29 | |
| 27 | 0624-233 | NUT, HEX - FLANGE W/SERRATIONS - 1/4-20 | 1 | $1.89 |
