1996 Arctic Cat MONTE CARLO 770 — REVERSE DEFLECTOR AND LEVER ASSEMBLY

1996 MONTE CARLO 770

Scroll / pinch to zoom · drag to pan · double-click resets

#	Part No.	Description	Qty	Price
1	0673-970	LEVER,REVERSE-WHITE	1	$131.29
2	1673-262	DEFLECTOR,REVERSE-MACH	1	$199.59
3	1673-142	MOUNT,LEVER-REVERSE	1	$38.29
4	0624-089	NUT,LOCK-HH 1/4 20 (SS)	1	$1.39
5	1673-143	ARM,LEVER-REVERSE	1	$13.59
6	0624-115	WASHER,LOCK-SL .250 SS	1	$0.21
7	0673-701	BRACKET,REVERSE CABLE SUPPORT	1	$11.29
8	1673-263	PLATE,CAM-LOCKING	1	$113.95
10	0624-125	WASHER FLAT,FENDER 8MM (SS)	1	$1.69
11	0624-250	NUT,LOCK-NSL M6-1.0 SS	1	$0.68
12	0624-155	SCREW,CAP-HH M5-.8X16 SS	1	$0.87
13	0673-556	CLAMP,REVERSE CABLE	1	$3.89
14	0624-005	NUT,LOCK-M5-.8 (SS)	1	$1.19
15	0673-931	ROD END,STEERING (10-32)	1	$50.95
16	0624-107	NUT,HEX-10-32 (SS)	1	$0.39
17	1673-261	ROD END	1	$42.59
18	0612-364	COVER,THREAD CAP-STEERING CABLE	1	$2.69
20	1673-193	GASKET,CABLE-FOAM	1	$3.49
21	0623-669	NUT,STEERING CABLE-NYLON	1	$2.95
22	0673-944	CABLE,REVERSE	1	$245.95
23	1673-152	PIVOT,UNIVERSAL	1	$16.59
24	0673-156	HANGER,BEARING DAMPENER ASSY	1	$397.79
25	0624-405	BUSHING	1	$12.29
26	0624-404	BUSHING	1	$12.95
27	0624-213	SCREW,CAP-HH M6-1.0 X 60 (SS)	1	$2.79
28	0624-028	WASHER,FLAT-8MM SS	1	$0.40
29	0624-395	SPACER	1	$3.29
30	0624-289	SCREW,CAP-HH 1/4-20 X 1 SS	1	$0.87
32	0675-070	SPACER,NOZZLE-STEERING	1	$2.69
33	0624-022	WASHER,FLAT-6MM SS	1	$0.22
34	0624-027	WASHER,LOCK-SL 8MM SS	1	$0.44
35	0624-182	WASHER,FLAT-6.4MM ID X 18MM OD X 1.6T (S	1	$0.52
37	0624-279	NUT,HEX-1/4-28 (SS)	1	$0.67
38	0624-012	WASHER,LOCK-10MM SL (SS)	1	$0.92
39	0624-407	NUT,HEX-M10X1.25 SS	1	$8.59
40	0624-046	SCREW,CAP-HH 6MM-1.0X16MM SS	1	$1.19
