1997 Arctic Cat MONTE CARLO 640 — DECAL AND FOOTPAD ASSEMBLY
1997 MONTE CARLO 640
Diagrams are watermarked to identify this site as the source of the reproduction and discourage scraping. The artwork is not ours — see Legal.
Prices are out of date. They are the last prices on record (approx. 2019) and are shown for reference only — nothing here is for sale. The archive data itself — part numbers, diagrams and supersessions — is still accurate.
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 0614-250 | DECAL,HATCH-RH | 1 | $76.59 | |
| 1 | 0614-251 | DECAL,HATCH-LH | 1 | $76.59 | |
| 2 | 0614-299 | DECAL,WARNING-FUEL | 1 | $7.95 | |
| 3 | 0614-300 | DECAL, OIL - USAGE | 1 | $8.59 | |
| 4 | 0614-328 | DECAL,DECK-UPPER-STRBRD BLUE PEARL | 1 | $29.95 | |
| 4 | 0614-329 | DECAL,DECK-UPPER-PORT BLUE PEARL | 1 | $29.95 | |
| 5 | 1673-218 | PAD,FOOT-REAR PURPLE | 1 | $185.95 | |
| 6 | 0614-254 | DECAL,HATCH-"640" | 1 | $14.59 | |
| 8 | 0614-253 | DECAL,INSTRUMENT PANEL | 1 | $20.95 | |
| 9 | 0614-248 | DECAL,HULL-RH | 1 | $86.59 | |
| 9 | 0614-249 | DECAL,HULL-LH | 1 | $86.59 | |
| 10 | 0614-252 | DECAL,DECK-TIGERSHARK | 1 | $69.59 | |
| 11 | 0623-665 | RIVET,AA48ABS SOFT SET-PURPLE | 1 | $0.33 | |
| 12 | 0614-246 | DECAL,SIDE-RH | 1 | $59.79 | |
| 12 | 0614-247 | DECAL,SIDE-LH | 1 | $58.29 | |
| 13 | 0614-245 | DECAL,CONSOLE | 1 | $11.79 | |
| 14 | 1673-181 | PLUG,MUSHROOM-DOMED-PURPLE | 1 | $0.92 | |
| 15 | 0617-185 | FOAM,DECK-LH | 1 | $108.95 | |
| 16 | 0614-067 | DECAL,USCG EXEMPTION | 1 | $9.95 | |
| 17 | 0614-154 | DECAL,CAUTION-UPRIGHTING | 1 | $12.29 | |
| 18 | 0614-155 | DECAL,REGULATION | 1 | $24.59 | |
| 19 | 0617-184 | FOAM,DECK-RH | 1 | $46.95 | |
| 20 | 1611-866 | DECAL,WARNING-GAS VAPORS | 1 | $4.69 |
