CRANKCASE ASSEMBLY
1998 TS-R 770
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3008-426 | CRANKCASE ASSY -770CC | 1 | $2,210.95 | |
| 2 | 3008-210 | BOLT, 6X35 | 1 | $4.19 | |
| 4 | 3008-212 | BOLT, 10X70 | 1 | $13.73 | |
| 5 | 3008-199 | PIN, KNOCK(ALIGNMENT) | 1 | $3.16 | |
| 7 | 3008-105 | BUSHING, PINION SHAFT | 1 | $41.95 | |
| 9 | 3008-200 | HOSE, VACUUM,M5.3X10.5X600 | 1 | $26.95 | |
| 10 | 3008-039 | CLIP, ID:10.5 | 1 | $3.49 |
